Soras Tech
1 / 5
| Item | Specification |
|---|---|
| PON Port |
• 1*GPON (Class B+ / C+) • Uplink 1.244Gbps, Downlink 2.488Gbps, 20Km • Maximum Split Ratio 1:128 |
| Uplink Ports |
• 1*10/100/1000Base-T RJ45 (2.5Gbps optional) • 1*10G Base-X SFP+ Optical Port |
| Dimensions | • 140mm x 87mm x 28mm (L x W x H) |
| Weight | • < 1 Kg |
| Power Consumption | • < 18W |
| Power Supply |
• DC Input: 12V/2A • POE (Optional) |
| Operating Temperature | • -10°C ~ +50°C |
| Storage Temperature | • -40°C ~ +70°C |
| Operating Humidity | • 5% ~ 95% (Non-condensing) |
| Software Features | |
|---|---|
| Management | GPON Functionality |
| • CLI (Telnet/SSH) | • Compliant with ITU-T 984.x |
| • Web UI (HTTP/HTTPS) | • Dynamic Bandwidth Allocation |
| Layer 2 Switching | • ONU Authentication: SN/Password/Loid |
| • 2K MAC Address Learning | • Supports Data Encryption |
| • Supports 4K VLANs | • Supports Uplink/Downlink FEC |
| • Supports Port VLAN: ACCESS / TRUNK | • Diagnosis and Link Monitoring |
| • Multicast, Broadcast, Unknown Unicast Storm Control | • ONU Upgrade |
| • Access Control List | Multicast |
| • Performance Statistics | • IGMPv2/IGMPv3 Snooping |
