Gonna upgrade to a bigger power supply with imported chips for rock-solid transmission.
Supports multiple installation methods and is convenient to use.
Premium metal casing with dual-side vents for better heat dissipation—ensuring high-speed operation and extended service life.
Allocate decoding processing power, strong recognition, long transmission range, interference resistance, low power consumption—delivering high device performance at lower costs.
Dual protection for power and Ethernet ports, 2KV rating, safe even in thunderstorms.
Stable 5V port for current transmission, 24/7 uninterrupted power, high temperature resistance, and circuit protection.
| Parameter | Details |
|---|---|
| Access mode | 10/100/1000Mbps SFP Media Converter |
| Standard | IEEE802.3 10Base-T Ethernet, IEEE802.3u 100Base-TX/FX Fast Ethernet, IEEE802.3ab 1000Base-T, IEEE802.3z 1000Base-SX/LX Gigabit Ethernet |
| Port | SFP Port |
| Transmission distance | Multi-mode Dual-fiber: 0.55km(850nm), 2KM(1310nm) |
| Single mode Dual-fiber: 20/40/60/80/100/120 Km | |
| Single mode Single fiber: 20/40/60/80/100/120 Km | |
| Category-5 twisted pairs: 100m | |
| Port | One RJ45 port: for connecting with STP/UTP category-5 twisted pairs |
| Optical port | Multi-mode Dual-fiber: SC/LC/ST(SFP) (50, 62.5/125μm) |
| Single mode Dual-fiber: SC/FC/ST/LC(SFP) (9/125μm) | |
| Single mode Single fiber: SC/FC/ST/LC(SFP) (9/125μm) | |
| Conversion means | Media conversion |
| BER | <10-9 |
| MTBF | 100,000 hours |
| LED indicator | POWER (power supply), FX LINK (optical link action), TP LINK1000 (TP cable rate 1000M), TP LINK100 (TP cable rate 100M), TP ACT(TP cable packet forwarding action) |
| Power supply | AC90V-260V( internal power ) |
| DC-48V, DC24V, DC12V, DC5V (external power) | |
| Power consumption | 5W |
| Operating temperature | -10~55ºC |
| Operating humidity | 5%~90% |
| Maintaining temperature | -40~70ºC |
| Maintaining humidity | 5% ~ 90% non-condensing |
| Dimensions | 71mm (W) * 94mm (D) * 26 mm (H) (external power supply) |
| Model | Introduction | Function |
|---|---|---|
| RD-GS5601-SFP | 10/100/1000MB to SFP Media Converter | 10/100/1000M media converter, 1*RJ45+1*SFP port, External DC5V power supply. |
Yes, we can do OEM products. It's no problem.
Every single optic module is individually tested in our test center, and also tested for compatibility on a variety of different network equipments.
Yes, we can provide samples for you to check the quality.
We accept T/T, western union, Alibaba order...
For usual order, we keep stock, could ship about 3 days after receiving the payment. For big quantity & special products, please check lead time with our sales.
We usually ship by DHL, UPS, FedEx or TNT. It usually takes 3-5 days to arrive.
