Point-to-multipoint high-speed forwarding
| Hardware Specifications | |
|---|---|
| Standard | • IEEE 802.3, IEEE 802.3u, IEEE 802.3ab, IEEE 802.3z, IEEE 802.3x |
| Interface | • 1*155Mbps SC optical fiber interface • 4*RJ45 10/100Mbps |
| Distance | • 100m @CTE5 • 20km @SMF |
| Wavelength | • A: Tx1310nm / Rx1550nm • B: Tx1550nm / Rx1310nm |
| Transmission Media | • Cable: CTE5 or higher UTP and STP • Optical Fiber: 9/125um single-mode optical fiber |
| Optical Parameter | • Average emission power: -9 to -3 dBm • Receiving sensitivity: -22 dBm |
| Power | DC5V/2A |
| Size | 94.5mm * 73mm * 27mm |
| Environment | • Operating temperature: -5℃ to 60℃ • Operating humidity: 10% to 90% RH (non-condensing) • Storage temperature: -40℃ to 70℃ • Storage humidity: 5% to 90% RH (non-condensing) |
| Order Info | |
|---|---|
| RD-FE104-T | Fiber Media Converter 10/100MB 1*SC+4*RJ45 1310-TX |
| RD-FE104-R | Fiber Media Converter 10/100MB 1*SC+4*RJ45 1550-TX |
It depends on the products. Different products have different MOQ. Please reach out to us for more details.
Yes, we can offer customization and ODM/OEM services to meet your specific requirements.
Yes, all of our products are unlocked and support compatibility with other brands as well.
We are the manufacturer, and we support factory view tours.
Yes, for some models we are able to provide free samples for testing purposes.
Yes, according to the contract agreement, we are able to apply for local certificates for you, such as Postel, CE, RoHS, Anatel, etc.
