| Specification parameters | |
|---|---|
| Standard | ● IEEE 802.3, IEEE 802.3u, IEEE 802.3ab, IEEE 802.3z, IEEE 802.3x |
| Interface | ● 2*1.25Gbps SC optical fiber interface ● 4*RJ45 10/100/1000Mbps |
| Distance | ● 100m @CTE5 ● 20km @SMF |
| Wavelength | ● A: Tx1310nm/Rx1550nm ● B: Tx1550nm/Rx1310nm |
| Transmission media | ● Cable: CTE5 or higher UTP and STP ● Optical Fiber: 9/125um single-mode optical fiber |
| Optical parameter | ● Average emission power: -9 to -3 dBm ● Receiving sensitivity: -22 dBm |
| Power | ● DC12V/2A |
| Size | ● 128mm*78mm*26mm |
| Environment | ● Operating temperature: -5℃ to 60℃ ● Operating humidity: 10% to 90% RH (non-condensing) ● Storage temperature: -40℃ to 70℃ ● Storage humidity: 5% to 90% RH (non-condensing) |
| Model | Description |
|---|---|
| RD-GE204 | Fiber Switch 10/100/1000MB 2*SC+4*RJ45 AB |
This product is set by default to have a fiber transmission distance of 20 kilometers. However, you can also purchase it based on the actual distance required.
A1: Depends on products, different products have different MOQ.
A2: Yes, we can offer the customization service to you.
A3: Yes, all of our products is without lock, support to another brands too.
A4: We are the manufacturer, we support factory view tour.
A5: Yes, for some models we are able to provide the free samples for your testing purpose.
A6: Yes, according the contract agreement, we are able to apply for the local certificates for you, such as Postel/CE/Rohs/Anatel etc.
