| Item | Specification |
|---|---|
| PON Port |
•1*GPON (Class B+ / C+)
•Uplink 1.244Gbps, Downlink 2.488Gbps, 20Km
•Maximum Split Ratio 1:128
|
| Uplink Ports |
•1*10/100/1000Base-T RJ45 (2.5Gbps optional)
•1*10G Base-X SFP+ Optical Port
|
| Dimensions |
•140mm x 87mm x 28mm (L x W x H)
|
| Weight |
•< 1 Kg
|
| Power Consumption |
•< 18W
|
| Power Supply |
•DC Input: 12V/2A
•POE (Optional)
|
| Operating Temperature |
•-10℃ ~ +50℃
|
| Storage Temperature |
•-40℃ ~ +70℃
|
| Operating Humidity |
•5% ~ 95% (Non-condensing)
|
| Software Features | |
|---|---|
| Management & Layer 2 Switching | GPON Functionality & Multicast |
|
▪CLI (Telnet/SSH)
▪Web UI (HTTP/HTTPS)
▪2K MAC Address Learning
▪Supports 4K VLANs
▪Supports Port VLAN: ACCESS, TRUNK
▪Multicast, Broadcast, Unknown Unicast Storm Control
▪Access Control List
▪Performance Statistics
|
▪Compliant with ITU-T 984.x
▪Dynamic Bandwidth Allocation
▪ONU Authentication: SN/Password/Loid
▪Supports Data Encryption
▪Supports Uplink/Downlink FEC
▪Diagnosis and Link Monitoring
▪ONU Upgrade
▪IGMPv2/IGMPv3 Snooping
|
