| Hardware | |
|---|---|
| ONT Type | SFU/HGU |
| Interface | 1*RJ45 (GE)+1*RJ45 (10GE) + XGSPON |
| LED | POWER+PON/LOS+INTERNET+1G+10G |
| CPU Frequency | 1 GHz Dual-Core |
| Flash & Memory | Flash: 128MB NAND; Memory: 512 DDR3 |
| Power Supply | 12V/1A |
| Power Consumption | ≤12W |
| Environment Standard |
Operating Temperature: -5℃~50℃ Storage Temperature: -20℃~70℃ Relative Humidity: 5%~95% (non-condensing) |
| Weight | 0.15KG |
| Size | 135mm*90mm*36mm (L*W*H) |
| Module Type | Class B+, SC/UPC |
| Wavelength | UP 1270nm, Down 1577nm |
| TX Optical Power | 5-9dBm |
| RX Optical Sensitivity | -28dBm |
| Transmission Distance | 0~20km |
| Transmission Rate | XGSPON: Upstream 10Gbps, Downstream: 10Gbps |
| LAN Interface Type |
1G : RJ45 (10/100/1000Mbps) 10G : RJ45 (1/2.5/5/10 Gbps) |
| Software | |
|---|---|
| Feature |
ITU-T G.987 ITU-T G.988/TR255/TR156 15 TCONTs /256GEM ports 8 Egress queues per TCONT at least VLAN/ priority/VEIP gem mapping mode SN/LOID/SN +Password authentication Performance monitoring: eth/Gem port Dying gasp |
| Ethernet Port |
Ethernet port-based VLAN tags and tag removal MAC address learning 10/100/1000/10000Mbps Auto negotiation |
| L2 Feature |
MAC learning (SVL)/aging Support max frame length to 1518 bytes VLAN tagging for untagged packets Support VLAN 1-4094 |
| L3 Feature |
PPPoE/Static IP/DHCP NAT/NAPT Port forwarding ALG, UPnP, DDNS IPv4/IPv6 dual stack, DS-Lite Static, and Default Routes Multiple services on one WAN port |
| QoS |
Support 8 Queues with Strict Priority Ethernet port rate limitation 802.1 priority SP/WRP Service flow classification |
| Multicast |
IGMP v2 (RFC 2236) and IGMP v3 (RFC 3376) IGMP snooping and IGMP Proxy MLD v1 |
| Management |
OMCI/WEB UI/TR069 Telnet/SSH Management with CLI commands Dual-system software backup and rollback |
| Description | Accessories Pack |
|---|---|
| 1*GE+1*10GE+XGSPON | Power Adapter, RJ45 cable |
