| Hardware Specifications Parameters | |
| Standard | ● IEEE 802.3, IEEE 802.3u, IEEE 802.3ab, IEEE 802.3z, IEEE 802.3x |
| Interface | ● 1*1.25Gbps SC optical fiber interface ● 8*RJ45 10/100/1000Mbps |
| Distance | ● 100m @CTE5 ● 20km @SMF |
| Wavelength | ● A:Tx1310nm/Rx1550nm ● B:Tx1550nm/Rx1310nm |
| Transmission media | ● Cable: CTE5 or higher UTP and STP ● Optical Fiber: 9/125um single-mode optical fiber |
| Optical parameter | ● Average emission power: -9 to -3 dBm ● Receiving sensitivity: -22 dBm |
| Power | ● DC5V/2A |
| Size | ● 195mm*92mm*28mm |
| Environment | ● Operating temperature: -5°C to 60°C ● Operating humidity: 10% to 90% RH (non-condensing) ● Storage temperature: -40°C to 70°C ● Storage humidity: 5% to 90% RH (non-condensing) |
| Model | Description |
| RD-GE108-T | Fiber Media Converter 10/100/1000MB 1*SC+8*RJ45 1310-TX |
| RD-GE108-R | Fiber Media Converter 10/100/1000MB 1*SC+8*RJ45 1550-TX |
