| Parameter | Details |
| Access mode | 10/100/1000Mbps Gigabit Ethernet Media Converter |
| Standard | IEEE802.3 10Base-T Ethernet, IEEE802.3u 100Base-TX/FX Fast Ethernet, IEEE802.3ab 1000Base-T, IEEE802.3z 1000Base-SX/LX Gigabit Ethernet |
| Wavelength | 850nm/1310nm/1550nm |
| Transmission distance |
Multi-mode Dual-fiber: 0.55km(850nm), 2KM(1310nm) Single mode Dual-fiber: 20/40/60/80/100/120 Km Category-5 twisted pairs: 100m |
| Port | One RJ45 port: for connecting with STP/UTP category-5 twisted pairs |
| Optical port |
Multi-mode Dual-fiber: SC/LC/ST(SFP) (50, 62.5/125μm) Single mode Dual-fiber: SC/FC/ST/LC(SFP) (9/125μm) |
| Conversion means | Media conversion |
| BER | <10-9 |
| MTBF | 100,000 hours |
| LED indicator | POWER, FX LINK, TP LINK1000, TP LINK100, TP ACT |
| Power supply | AC90V-260V (internal), DC-48V, DC24V, DC12V, DC5V (external) |
| Operating Temperature | -10~55ºC |
| Dimensions | 71mm (W) * 94mm (D)*26 mm (H) |
| Model | Introduction | Function |
| RD-GS5601-M20A/B | Mini Fiber Media Converter 10/100/1000Mbps 20km | 1*Simplex SC -1*LAN SM 20km SC DC5V power supply, A:Tx1310nm/Rx1550nm; B:Tx1550nm/Rx1310nm |
| RD-GS5601-20A/B | Fiber Media Converter 10/100/1000Mbps 20km | 1*Simplex SC -1*LAN SM 20km SC DC5V power supply, A:Tx1310nm/Rx1550nm; B:Tx1550nm/Rx1310nm |
| RD-GS5601-S20 | Fiber Media Converter 10/100/1000Mbps 20km | 1*Duplex SC -1*LAN SM 20km SC DC5V power supply, TRx:1310nm |
| RD-GS5601-SFP | 10/100/1000MB to SFP Media Converter | 1*RJ45 + 1*SFP port, External DC5V power supply. |
| RD-GS5601-SFP MINI | MINI 10/100/1000MB to SFP Media Converter | 1*RJ45 + 1*SFP port, media converter only. |
