| Parameter | Details |
|---|---|
| Part Number | HTB-3100AB |
| Standards | IEEE 802.3 10Base-T IEEE 802.3u 100Base-TX |
| Ethernet Port | Connector: RJ45 Data Rate: 10/100Mbps Distance: 100m UTP Type: UTP-5E or higher level |
| Fiber Port | Connector: SC port Data Rate: 10/100Mbps Distance: 25km |
| Port Config | 1*RJ45 port, 1* fiber port (SC/LC/ST/FC Optional) |
| Forward / Filter Rate | 10M: 14,880/14,880pps 100M: 148,800/148,800pps |
| Power Supply | External : 5V DC 1A Built-in: 100 V to 240 V AC 50Hz to 60Hz Power Consumption : ≤5W |
| Operating Temperature | 0 °C to +70 °C |
| Storage Temperature | -20 °C to +80 °C |
| Relative Humidity | 5% to 90% (non-condensing) |
| Warranty | 1 Year |
| Model | Introduction | Function Description |
|---|---|---|
| HTB-3100AB | Fiber Media Converter 10/100Mbps 25km | Fiber Media Converter, 10/100Mbps 1*Simplex SC - 1*LAN SM 25km SC DC5V power supply A: Tx1310nm/Rx1550nm B: Tx1550nm/Rx1310nm |
| HTB-GS03AB | Fiber Media Converter 10/100/1000Mbps 3km | Fiber Media Converter, 10/100/1000Mbps 1*Simplex SC - 1*LAN SM 3km SC DC5V power supply A: Tx1310nm/Rx1550nm B: Tx1550nm/Rx1310nm |
| HTB-GS03-20AB | Fiber Media Converter 10/100/1000Mbps 20km | Fiber Media Converter, 10/100/1000Mbps 1*Simplex SC - 1*LAN SM 20km SC DC5V power supply A: Tx1310nm/Rx1550nm B: Tx1550nm/Rx1310nm |
1. How is the quality of the optical fiber transceivers guaranteed?
We maintain strict quality control by inspecting pre-production samples before mass production and conducting a 100% final inspection before shipment.
2. What types of fiber optic equipment are available?
We offer a wide range of products including FTTH ONU/OLT, SFP Modules, Fiber Media Converters, PoE Switches, and other fiber optic equipment.
3. What payment methods and delivery terms do you support?
Supported Delivery Terms: FOB, CFR, CIF, EXW, DDP, Express Delivery. Supported Payment Methods: T/T, L/C, PayPal, Western Union, Credit Card, Escrow, etc. Supported Currencies include USD, EUR, CNY, etc.
4. What is the maximum transmission distance of the HTB-3100AB converter?
The HTB-3100AB supports data transmission over a distance of up to 25km using single-mode fiber.
5. What standard protocols does the 10/100Mbps fiber media converter comply with?
It complies fully with the IEEE 802.3 10Base-T and IEEE 802.3u 100Base-TX standards to ensure high compatibility with your existing network infrastructure.
6. What type of fiber connector ports does this device use?
The default is a simplex SC port. Optionally, LC, ST, or FC fiber ports can be configured depending on the project requirements.
