EG8141A5 HG8546M HG8545M5 2.4GWifi 5dbI Antenna Ftth ONU ONT Fiber Optic Equipment English Firmware
EG8141A5 HG8546M HG8545M5 2.4GWifi 5dbI Antenna Ftth ONU ONT Fiber Optic Equipment English Firmware
EG8141A5 HG8546M HG8545M5 2.4GWifi 5dbI Antenna Ftth ONU ONT Fiber Optic Equipment English Firmware
EG8141A5 HG8546M HG8545M5 2.4GWifi 5dbI Antenna Ftth ONU ONT Fiber Optic Equipment English Firmware
EG8141A5 HG8546M HG8545M5 2.4GWifi 5dbI Antenna Ftth ONU ONT Fiber Optic Equipment English Firmware
1 / 5
EG8141A5 HG8546M HG8545M5 2.4GWifi 5dbI Antenna Ftth ONU ONT Fiber Optic Equipment English Firmware
EG8141A5 HG8546M HG8545M5 2.4GWifi 5dbI Antenna Ftth ONU ONT Fiber Optic Equipment English Firmware
EG8141A5 HG8546M HG8545M5 2.4GWifi 5dbI Antenna Ftth ONU ONT Fiber Optic Equipment English Firmware
EG8141A5 HG8546M HG8545M5 2.4GWifi 5dbI Antenna Ftth ONU ONT Fiber Optic Equipment English Firmware
EG8141A5 HG8546M HG8545M5 2.4GWifi 5dbI Antenna Ftth ONU ONT Fiber Optic Equipment English Firmware

EG8141A5 HG8546M HG8545M5 2.4GWifi 5dbI Antenna Ftth ONU ONT Fiber Optic Equipment English Firmware

Send Inquiry

Product Description

Product Image
Product Design
Product Design 1 Product Design 2 Product Design 3
Specification
Model HG8546M EG8141A5
Out Port contains 1GE+3FE+1POT+1UB+WiFi
WIFI signal 2.4GHz wifi
Wireless gain 5db
USB 2.0
LAN 1*10/100/1000Mbps adaptive Ethernet ports, full/half duplex, RJ45 interface
TEL H248/SIP Voice Protocol
PPPOE BRIDGE Support
Firmware English
Dimension/weight 153mm*125mm*32mm/176g
Fiber port 1 GPON /EPON interface, single-fiber, Downstream rate 2.5Gbps; Upstream rate 1.25Gbps
Wavelength Tx 1310nm, Rx 1490nm
Fiber interface SC/UPC /APC Single mode
RX sensitivity >-28dBm (1490nm)
DC power 12V 1.0A, external AC-DC power adapter
Operation Working temperature: -5 to +55°C; working humidity: 10-90% (non-condensation)
Storage Storage temperature: -30 to +60°C; storage humidity: 10-90% (non-condensation)
Company Profile
Company Profile Image
FAQ
Who Are We?
We are an optical communication manufacturer founded in 2017. Our products are sold worldwide, with key markets including Asia, North America, Europe, the Middle East, and South America. We have a 11-50 person team dedicated to serving global clients.
How Do We Guarantee Quality?
We guarantee quality through:
  • Pre-production samples before mass production
  • 100% final inspection before shipment
What Can You Buy From Us?
You can purchase FTTH ONU/OLT, SFP Modules, Fiber Media Converters, PoE Switches, and other fiber optic equipment.
Why Choose Us?
We are a top-tier optical communication supplier with over 50 employees. Our core focus is on PON and switching solutions, supported by a strong engineering team. We deliver reliable products and value-added service for partners worldwide.
What Services Can We Provide?
We provide a wide range of services and support options:
  • Delivery Terms: FOB, CFR, CIF, EXW, DDP, Express Delivery, etc.
  • Payment Currencies: USD, EUR, CNY, and more
  • Payment Methods: T/T, L/C, PayPal, Western Union, Credit Card, Escrow, etc.
  • Languages Supported: English, Chinese, Spanish, French, Russian, and more
What are the environmental requirements for these devices?
The devices support the following operating and storage environments:
  • Operating Temperature: -5 to +55°C (Working humidity: 10-90%, non-condensation)
  • Storage Temperature: -30 to +60°C (Storage humidity: 10-90%, non-condensation)
