| Hardware Parameters | |
|---|---|
| Standard | IEEE 802.3, IEEE 802.3u, IEEE 802.3ab, IEEE 802.3z, IEEE 802.3x |
| Interface |
● 2*155Mbps SC optical fiber interface
● 4*RJ45 10/100Mbps
|
| Distance |
● 100m @CTE5
● 20km @SMF
|
| Wavelength |
● A: Tx1310nm / Rx1550nm
● B: Tx1550nm / Rx1310nm
|
| Transmission media |
● Cable: CTE5 or higher UTP and STP
● Optical Fiber: 9/125um single-mode optical fiber
|
| Optical parameter |
● Average emission power: -9 to -3 dBm
● Receiving sensitivity: -22 dBm
|
| Power |
● DC5V/2A
|
| Size |
● 94mm*73mm*26mm
|
| Environment |
● Operating temperature: -5°C to 60°C
● Operating humidity: 10% to 90% RH (non-condensing)
● Storage temperature: -40°C to 70°C
● Storage humidity: 5% to 90% RH (non-condensing)
|
| Model Number | Description |
|---|---|
| RD-FE204 | Fiber Switch 10/100MB 2*SC+4*RJ45 AB |
