| Technical Parameters | ||
|---|---|---|
| Agreement | Standard | IEEE802.3 10Base-T, IEEE802.3u 100Base-TX, IEEE802.3ab 1000Base-T, IEEE802.1W Spanning Tree, IEEE 802.3x flow control |
| Network Characteristics | Interface Type | 4* PoE, 1* RJ45 UPLINK |
| Transmission Rate | 10/100/1000Mbps Adaptive | |
| Transmission Distance |
10Base-T: ≤250m (CAT3,4,5 UTP) 100Base-TX: ≤100m (CAT3,4,5 UTP) 1000Base-T: ≤100m (CAT3,4,5 UTP) |
|
| Performance | Pass-through Mode | Store-and-forward (full line speed) |
| Transmission Mode | Full duplex/half duplex adaptive | |
| MAC Address Table | 2K | |
| Buffer Memory | 768Kb | |
| Frame Size | 2048b | |
| Packet Forwarding Rate | 0.89Mpps@64byte | |
| Backplane Bandwidth | 1.2G | |
| LED Indicators | Power | Blue |
| Link/Act | Blue | |
| PoE | Blue | |
| 1000M | Blue * 2 | |
| Power Supply | Input Voltage | AC100~240V, 50Hz |
| Power Consumption | Standby: ≤3W; Full Load: ≤65W | |
| PoE Line Pin | 1/2+, 3/6- | |
| Maximum PoE Power | ≤25.4W | |
| Working Environment | Operating Temp | -20°C ~ 60°C |
| Storage Temp | -40°C ~ 85°C | |
| Humidity | 5% ~ 95% (No condensation) | |
| Physical Dimensions | Size | 201 × 118 × 44mm |
| Weight | N.W: 0.92kg, G.W: 1.02kg | |
