| Model | GM220-S |
| User interface | 3*10/100M RJ45, 1*10/100/1000M RJ45, 1*USB, 1*VOIP, 1*WiFi |
| PON |
Transmission speed: upstream 1.25Gbps / downstream 2.5Gbps
Network coverage radius: 20km
Optical receive sensitivity: ≤-28dBm
Luminous power: <0dBm
Security: ONU authentication mechanism
|
| WiFi | IEEE 802.11b/g/n WIFI (300Mbps) |
| Protocol |
Compliant with IEEE 802.3ah
YD/T 1475-2006
IEEE 802.1D, Spanning Tree
IEEE 802.1Q, VLAN
IEEE 802.1b/g/n
IEEE 802.1w, RSTP
IEEE 802.3ad (LACP)
Ethernet–II, Ethernet-SNAP
|
| VLAN | Port-based VLAN, GVRP, IEEE 802.1Q VLAN |
| QoS |
Backpressure flow control (half-duplex)
IEEE 802.3x flow control (full-duplex)
Prevent head of line
WR, SP queue scheduling algorithm
Port rate limit
|
| Security |
IEEE 802.1x, access control based on port; support local and remote RADIUS
CHAP, EAP certification
Storm control, port protection
|
| Management | Support various management modes such as Web, TELNET; Support debug function |
| Environment |
Operating temperature: 0℃~60℃; Operating humidity: 10%~85% (no-condensation)
Storage temperature: -40℃~80℃; Storage humidity: 5%~95% (no-condensation)
|
| Power supply | Input AC 110~240V, Output DC 12V/1A |
| Power Consumption | 12W |
| Part Number | Description | Accessories Pack |
|---|---|---|
| GM220-S | 1*GPON+1*GE+1*FE+1*USB+1*VOIP+1*WIFI | AC-DC Power Adapter DC12V/1A |
