Soras Tech
1 / 5
| Hardware Specifications | |
|---|---|
| Standard | IEEE 802.3, IEEE 802.3u, IEEE 802.3ab, IEEE 802.3z, IEEE 802.3x |
| Interface |
• 2*155Mbps SC optical fiber interface • 4*RJ45 10/100Mbps |
| Distance |
• 100m @CTE5 • 20km @SMF |
| Wavelength |
• A: Tx1310nm / Rx1550nm • B: Tx1550nm / Rx1310nm |
| Transmission media |
• Cable: CTE5 or higher UTP and STP • Optical Fiber: 9/125um single-mode optical fiber |
| Optical parameter |
• Average emission power: -9 to -3 dBm • Receiving sensitivity: -22 dBm |
| Power | DC5V/2A |
| Size | 94mm * 73mm * 26mm |
| Environment |
• Operating temperature: -5°C to 60°C • Operating humidity: 10% to 90% RH (non-condensing) • Storage temperature: -40°C to 70°C • Storage humidity: 5% to 90% RH (non-condensing) |
| Order Info | |
|---|---|
| RD-FE204 | Fiber Switch 10/100MB 2*SC+4*RJ45 AB |
